NETCDFFileData Class Reference

#include <netcdffiledata.h>

Inheritance diagram for NETCDFFileData:

Collaboration diagram for NETCDFFileData:

List of all members.

Public Member Functions
	NETCDFFileData (const string &filename, const string &mode)
virtual void *	read_data (void *data, const char *sds_name, int *start=NULL, int *stride=NULL, int *edges=NULL, int rank=-1)
	Read the selected data in the file.
virtual vector< int >	get_dataset_dimension (const string &sds_name)
	return the given dataset size along each axis
virtual bool	dataset_exists (const char *sds_name)
void	get_dataset_fill_value (const string &sds_name, void *fill_value)
	read the given dataset's fill value TODO Same method with many names of this method transfered from filedatareader. Need to be reformatted after functionnal tests with Data2Grid/MapsOperator
int	get_n_dataset ()
string	get_dataset_name (int i)
int	get_dataset_data_type (string sds_name)
string	get_values_attr_dataset (string sds_name, string attr_name)
bool	has_attr_dataset (string sds_name, string attr_name)
void	close_data_file ()
	closes the file
void	open_data_file ()
	open the file
Protected Member Functions
const bool	check_read_write_limits (const char *sds_name, int *start, int *stride, int *edges, const int rank)
void	init_read_write_null_input_param (const char *sds_name, int *&start, int *&stride, int *&edges, int &rank, bool *initialized_values)
void	free_read_write_allocations (const bool *are_limits_initialized, int *start, int *stride, int *edges)
Hdf_sds	get_dataset (string sds_name)
Protected Attributes
int32	ncfile
string	filename

---

Detailed Description

Author:

James MANLEY

---

Member Function Documentation

vector< int > NETCDFFileData::get_dataset_dimension

(

const string &

sds_name

)

[virtual]

return the given dataset size along each axis

Parameters:

ds_name

[IN] dataset name

Returns:

the axis dimensions in ordering [..., Z, Y, X]

Reimplemented from FileData.

References FileData::name.

Referenced by read_data().

void NETCDFFileData::get_dataset_fill_value	(	const string &	ds_name,
		void *	fillvalue
	)			[virtual]

read the given dataset's fill value TODO Same method with many names of this method transfered from filedatareader. Need to be reformatted after functionnal tests with Data2Grid/MapsOperator

Parameters:

	ds_name	[IN] dataset name
	fillvalue	[OUT] fill value.

Reimplemented from FileData.

void * NETCDFFileData::read_data	(	void *	data,
		const char *	sds_name,
		int *	start = NULL,
		int *	stride = NULL,
		int *	edges = NULL,
		int	rank = -1
	)			[virtual]

Read the selected data in the file.

Warning:

If you delegate the allocation of the buffer at this method, you need to call delete[] data yourself.

Parameters:

	data	the buffer to fill with the read values. Can be NULL. In this case, the allocation is done by the method
	sds_name	the name of the sds (Scientific Data Set) we want to access.
	start	begining of the selection. If NULL, start at (0,0) if rank is 2 ; (0,0,0) if rank is 3...
	stride	step between 2 interesting values. If NULL, this step is set to 1 in each dimension (ie all values will be read)
	edges	number of values to be read in each dimension. if NULL, it will be all data along each dimension.
	rank	the dimension of start, stride and edges

Returns:

a pointer to the read data array. It is useful when you let this method manage the allocation to update the allocated pointer to the data. If you've done it yourself or you are using a static buffer, it isn't necessary to catch this return pointer

Implements FileData.

References get_dataset_dimension(), and FileData::name.

---

The documentation for this class was generated from the following files:

• /home/pascal/depot/filedata/src/netcdffiledata.h
• /home/pascal/depot/filedata/src/netcdffiledata.cpp
