Inheritance diagram for OMIFileData:

Collaboration diagram for OMIFileData:

Public Member Functions
	OMIFileData (const string &_name, const string &mode="r")
	Constructor.
	~OMIFileData ()
	Destructor :
const bool	get_index (const float &lat, const float &lon, const double &time, int *near_point_idx, const float coloc_tolerance=OMIFileData::colocation_tolerance)
	search the index of the nearest point in the data to (lat , lon ) If coloc_tolerance is given, it will compute only the distance of the points that have a distance to ( lat, lon ) inferior to coloc_tolerance
const int	get_nearest_point_index (const float &lat, const float &lon, const double &time)
const bool	contains_data_at (const float &lat, const float &lon, const double &time) const
void	load_geolocation_data ()
const bool	get_index (const float &lat, const float &lon, int &nearest_pix_idx, const float colocation_tolerance=OMIFileData::colocation_tolerance)
	find the index of the nearest point to (lat,lon) in the data. If (lat,lon) is not found or out of the colocalisation_frame, returned indexes are [-1,-1]
const float	get_nearest_point_distance (const float &lat, const float &lon, const float coloc_tolerance=OMIFileData::colocation_tolerance)
	compute the distance to (lat,lon) of the nearest point in the data If coloc_tolerance is given, it will compute only the distance of the points that have a distance to ( lat, lon ) inferior to coloc_tolerance
const bool	contain_location (const float &lat, const float &lon, const double &tolerance=OMIFileData::colocation_tolerance)
	check if this file has eventually data coincident with (lat,lon) Actually, it only tests if (lat,lon) is contained in the data's bounding rectangle.
const bool	contain_data (const float &lat, const float &lon, const double &time, const double &colocation_tolerance=OMIFileData::colocation_tolerance)
	check if the file has possible (lat,lon) coincidence
virtual void	get_pixel_coord (const vector< int > &ipix, float &lat, float &lon, double &time)
	retrieve the coordinates of a pixel using its index
virtual void	get_vindex (vector< vector< int > > &v_index, const float &lat, const float &lon, const float colocation_tolerance)
	build the list of indices of pixels that are in colocation tolerance, sorted by increasing distance to (lat,lon) If (lat,lon) is not found or out of the colocalisation_frame, returns an empty vector
void	load_v_pixel ()
virtual void	close_data_file ()
	closes the file.
virtual void	open_data_file ()
	opens the file.
const int	get_sz_x () const
	accessor to the geolocation datasets swath size (in pixels)
const int	get_sz_y () const
	accessor to the geolocation datasets along track size (in pixels)
Protected Member Functions
void	init ()
void	check_filename (const string &short_filename) const
void	parse_filename (const string &short_filename)
Protected Attributes
int	track_size
vector< int >	lat_lon_index_max
Static Protected Attributes
static const string	latitude_sds_name = "Latitude"
static const string	longitude_sds_name = "Longitude"
static const string	time_sds_name = "Time"
static const float	colocation_tolerance = 0.05

Constructor & Destructor Documentation

OMIFileData::OMIFileData	(	const string &	_name,
		const string &	mode = `"r"`
	)

Constructor.

Parameters:

	_name	the name (path+filename) of the file to be opened
	mode	the opening mode. LIMITATION : only "r" mode treated at this time

Member Function Documentation

const bool OMIFileData::contain_data	(	const float &	lat,
		const float &	lon,
		const double &	time,
		const double &	colocation_tolerance = `OMIFileData::colocation_tolerance`
	)			`[virtual]`

check if the file has possible (lat,lon) coincidence

Warning:: it's an EVENTUAL coincidence. That is not a proof !!!

Parameters:

	lat	latitude
	lon	longitude
	time	time
	colocation_tolerance	the acceptable bias (in km or degrees. Supposed to be in, a plane approximation) between [lat,lon] and the nearest data point.

Returns:: true if can eventually contain a coincidence with the point.

Warning:: at this time always true. I don't have a good way to do it

Reimplemented from FileData.

References contain_location(), and FileData::contain_time().

const bool OMIFileData::contain_location	(	const float &	lat,
		const float &	lon,
		const double &	tolerance = `OMIFileData::colocation_tolerance`
	)			`[virtual]`

check if this file has eventually data coincident with (lat,lon) Actually, it only tests if (lat,lon) is contained in the data's bounding rectangle.

Parameters:

	lat	the latitude of the event
	lon	the longitude of the event
	tolerance	acceptable bias between the nearest point in the data and the given (lat,lon) point

Returns:: true if a point in the data has been found in the colocation frame

Reimplemented from FileData.

References colocation_tolerance, and get_index().

Referenced by contain_data().

const bool OMIFileData::contains_data_at	(	const float &	lat,
		const float &	lon,
		const double &	time
	)			const `[inline]`

check if this file has data coincident with (lat,lon,time)

Parameters:

	lat	the latitude of the event
	lon	the longitude of the event
	time	the time of the event

Returns:

const bool OMIFileData::get_index	(	const float &	lat,
		const float &	lon,
		int &	nearest_pix_idx,
		const float	colocation_tolerance = `OMIFileData::colocation_tolerance`
	)

find the index of the nearest point to (lat,lon) in the data. If (lat,lon) is not found or out of the colocalisation_frame, returned indexes are [-1,-1]

Parameters:

	lat	the latitude
	lon	the longitude
	nearest_pix_idx	the index of the nearest measure. -1 if no coincidence found.
	colocation_tolerance	the acceptable bias (in km or degrees. Supposed to be in, a plane approximation) between [lat,lon] and the nearest data point.

Returns:: true if the coincidence has been found

References get_index().

const bool OMIFileData::get_index	(	const float &	lat,
		const float &	lon,
		const double &	time,
		int *	near_point_idx,
		const float	coloc_tolerance = `OMIFileData::colocation_tolerance`
	)

search the index of the nearest point in the data to (lat , lon ) If coloc_tolerance is given, it will compute only the distance of the points that have a distance to ( lat, lon ) inferior to coloc_tolerance

Parameters:

	near_point_idx	the indexes of the nearest point found (or {-1,-1} if not found)
	lat	the latitude
	lon	the longitude
	time	the time of the observation. If -1., skipped
	coloc_tolerance	the -/+ maximal tolerance for 2 points considered as colocated

Returns:: true if found

References SatelliteFileData::free_geolocation_data(), SatelliteFileData::is_geolocation_data_loaded(), load_geolocation_data(), and SatelliteFileData::v_pixel.

Referenced by contain_location(), get_index(), and get_nearest_point_distance().

const float OMIFileData::get_nearest_point_distance	(	const float &	lat,
		const float &	lon,
		const float	coloc_tolerance = `OMIFileData::colocation_tolerance`
	)

compute the distance to (lat,lon) of the nearest point in the data If coloc_tolerance is given, it will compute only the distance of the points that have a distance to ( lat, lon ) inferior to coloc_tolerance

Parameters:

	lat	the latitude
	lon	the longitude
	coloc_tolerance	the -/+ maximal tolerance for 2 points considered as colocated

Returns:: the distance to the nearest point, or -1 if no point in the colocalisation frame has been found.

References SatelliteFileData::free_geolocation_data(), get_index(), SatelliteFileData::is_geolocation_data_loaded(), SatelliteFileData::lat_data, load_geolocation_data(), and SatelliteFileData::lon_data.

const int OMIFileData::get_nearest_point_index	(	const float &	lat,
		const float &	lon,
		const double &	time
	)

find the row index of the nearest point in the data of this file to (lat,lon,time). Be careful, it will return a valid index : this method doesn't check if the point given in parametre is contained in this file. Use the contains_data_at to check it first.

Parameters:

	lat	the latitude of the event
	lon	the longitude of the event
	time	the time of the event

Returns:: the nearest point row index

References SatelliteFileData::free_geolocation_data(), SatelliteFileData::is_geolocation_data_loaded(), SatelliteFileData::lat_data, load_geolocation_data(), and SatelliteFileData::lon_data.

virtual void OMIFileData::get_pixel_coord	(	const vector< int > &	ipix,
		float &	lat,
		float &	lon,
		double &	time
	)			`[inline, virtual]`

retrieve the coordinates of a pixel using its index

Parameters:

	ipix	[IN] index of the pixel
	lat	[OUT] latitude of the pixel
	lon	[OUT] longitude of the pixel
	time	[OUT] timestamp of the pixel

const int OMIFileData::get_sz_x ( ) const [inline]

accessor to the geolocation datasets swath size (in pixels)

Returns:: number of pixels along x dimension

const int OMIFileData::get_sz_y ( ) const [inline]

accessor to the geolocation datasets along track size (in pixels)

Returns:: number of pixels along y dimension

virtual void OMIFileData::get_vindex	(	vector< vector< int > > &	v_index,
		const float &	lat,
		const float &	lon,
		const float	colocation_tolerance
	)			`[inline, virtual]`

build the list of indices of pixels that are in colocation tolerance, sorted by increasing distance to (lat,lon) If (lat,lon) is not found or out of the colocalisation_frame, returns an empty vector

Parameters:

	lat	the latitude
	lon	the longitude
	colocation_tolerance	the acceptable bias (in km or degrees. Supposed to be in, a plane approximation) between [lat,lon] and the nearest data point.
