#include <ceresfiledata.h>

Inheritance diagram for CERESFileData:

Collaboration diagram for CERESFileData:

Public Member Functions
	CERESFileData (const string &name, const string &mode="r")
	~CERESFileData ()
void	set_lat_lon_index_max ()
const string	get_product () const
const string	get_platform () const
const string	get_instrument () const
const string	get_version () const
const string	get_radix () const
virtual const bool	get_index (const float &lat, const float &lon, const double time, int &index, const float coloc_tolerance=CERESFileData::colocation_tolerance)
	search the index of the nearest point in the data to (lat , lon ) It uses a brute force search on the whole data. For better performances, override this method, and use more specifics way like sort the pixels by increasing (lat,lon) then dichotomic search on it... Only the points that have a distance to ( lat, lon ) inferior to coloc_tolerance will be considered
virtual const float	get_nearest_point_distance (const float &lat, const float &lon, int &coincidence_idx, float coloc_tolerance=CERESFileData::colocation_tolerance)
	compute the distance to (lat,lon) of the nearest point in the data Only the points that have a distance to ( lat, lon ) inferior to coloc_tolerance will be considered In the method, calls the get_index method
virtual const bool	contain_location (const float &lat, const float &lon, float tolerance=CERESFileData::colocation_tolerance)
	check if this file has data coincident with ( lat , lon ) at a distance not bigger than tolerance
virtual void	load_geolocation_data ()
	read the geolocations data and put it in memory This method is used to make the search of the indexes of a (lat,lon,time) point faster.
virtual void	free_geolocation_data ()
	free eventually loaded geolocation data
virtual const bool	is_geolocation_data_loaded () const
	check if the geolocation data have been already loaded
const int	get_nb_geo_points () const
	access the number of differents geographical points in the file
const bool	get_index (const float &lat, const float &lon, int &nearest_pix_idx, const float colocation_tolerance=CERESFileData::colocation_tolerance)
	find the index of the nearest point to (lat,lon) in the data. If (lat,lon) is not found or out of the colocalisation_frame, returned indexes are [-1,-1]
virtual void	get_vindex (vector< vector< int > > &v_index, const float &lat, const float &lon, const float colocation_tolerance=CERESFileData::colocation_tolerance)
	build the list of indices of pixels that are in colocation tolerance, sorted by increasing distance to (lat,lon) If (lat,lon) is not found or out of the colocalisation_frame, returns an empty vector
const float	get_nearest_point_distance (const float &lat, const float &lon, const float coloc_tolerance=CERESFileData::colocation_tolerance)
	compute the distance to (lat,lon) of the nearest point in the data If coloc_tolerance is given, it will compute only the distance of the points that have a distance to ( lat, lon ) inferior to coloc_tolerance
const bool	contain_location (const float &lat, const float &lon, const double &tolerance=CERESFileData::colocation_tolerance)
	check if this file has eventually data coincident with (lat,lon) Actually, it only tests if (lat,lon) is contained in the data's bounding rectangle.
const bool	contain_data (const float &lat, const float &lon, const double &time, const double &colocation_tolerance=CERESFileData::colocation_tolerance)
	check if the file has possible (lat,lon) coincidence
virtual void	close_data_file ()
	closes the file.
virtual void	open_data_file ()
	opens the file.
virtual void	get_pixel_coord (const vector< int > &ipix, float &lat, float &lon, double &time)
	retrieve the coordinates of a pixel using its index
Static Public Member Functions
static const float	get_ceres_lon (const float &lon)
	convert a usual longitude in degrees (-180->180) to a longitude in CERES convention (0->360 where the 0 is the greenwich mereidian)
static const float	get_ceres_lat (const float &lat)
	convert a usual latitude in degrees (-90->90) to a colatitude, the convention used in CERES files (colat=90-lat)
Protected Member Functions
void	init ()
void	parse_filename (const string &short_filename)
bool	check_filename (const string &short_filename) const
const string	get_time_sds_name (const string product="") const
virtual void	load_v_pixel ()
	load the list data pixels
Protected Attributes
string	product
string	platform
string	instrument
string	version
int	lat_lon_index_max [1]
Static Protected Attributes
static const string	latitude_sds_name = "Colatitude of CERES FOV at surface"
static const string	longitude_sds_name = "Longitude of CERES FOV at surface"
static const float	colocation_tolerance = 0.2

Detailed Description

class managing the reading of the CERES file data. CERES products managed : CRS ; SSF ;

Author:: nicolas PASCAL

Constructor & Destructor Documentation

CERESFileData::CERESFileData	(	const string &	name,
		const string &	mode = `"r"`
	)

Constructor

Parameters:

	name	the name (path+filename) of the file to be opened
	mode	the opening mode. LIMITATION : only "r" mode treated at this time

References init().

CERESFileData::~CERESFileData ( )

Destructor

References free_geolocation_data(), HDFFileData::free_hdf_file(), and HDFFileData::free_hdf_metadata().

Member Function Documentation

const bool CERESFileData::contain_data	(	const float &	lat,
		const float &	lon,
		const double &	time,
		const double &	colocation_tolerance = `CERESFileData::colocation_tolerance`
	)			`[virtual]`

check if the file has possible (lat,lon) coincidence

Warning:: it's an EVENTUAL coincidence. That is not a proof !!!

Parameters:

	lat	latitude
	lon	longitude
	time	time
	colocation_tolerance	the acceptable bias (in km or degrees. Supposed to be in, a plane approximation) between [lat,lon] and the nearest data point.

Returns:: true if can eventually contain a coincidence with the point.

Warning:: at this time always true. I don't have a good way to do it

Reimplemented from FileData.

References contain_location(), and FileData::contain_time().

const bool CERESFileData::contain_location	(	const float &	lat,
		const float &	lon,
		float	tolerance = `CERESFileData::colocation_tolerance`
	)			`[virtual]`

check if this file has data coincident with ( lat , lon ) at a distance not bigger than tolerance

Parameters:

	lat	the latitude of the event
	lon	the longitude of the event

Returns:

References get_index(), and is_geolocation_data_loaded().

Referenced by contain_data().

const bool CERESFileData::contain_location	(	const float &	lat,
		const float &	lon,
		const double &	tolerance = `CERESFileData::colocation_tolerance`
	)			`[virtual]`

check if this file has eventually data coincident with (lat,lon) Actually, it only tests if (lat,lon) is contained in the data's bounding rectangle.

Parameters:

	lat	the latitude of the event
	lon	the longitude of the event
	tolerance	acceptable bias between the nearest point in the data and the given (lat,lon) point

Returns:: true if a point in the data has been found in the colocation frame

Reimplemented from FileData.

References get_index().

const float CERESFileData::get_ceres_lat ( const float & lat ) [static]

convert a usual latitude in degrees (-90->90) to a colatitude, the convention used in CERES files (colat=90-lat)

Parameters:

lat

a latitude

Returns:: the colatitude corresponding to lat

Referenced by get_index(), and get_nearest_point_distance().

const float CERESFileData::get_ceres_lon ( const float & lon ) [static]

convert a usual longitude in degrees (-180->180) to a longitude in CERES convention (0->360 where the 0 is the greenwich mereidian)

Parameters:

lon

a usual longitude

Returns:: the longitude used in CERES

Referenced by get_index(), and get_nearest_point_distance().

const bool CERESFileData::get_index	(	const float &	lat,
		const float &	lon,
		int &	nearest_pix_idx,
		const float	colocation_tolerance = `CERESFileData::colocation_tolerance`
	)

find the index of the nearest point to (lat,lon) in the data. If (lat,lon) is not found or out of the colocalisation_frame, returned indexes are [-1,-1]

Parameters:

	lat	the latitude
	lon	the longitude
	nearest_pix_idx	the index of the nearest measure. -1 if no coincidence found.
	colocation_tolerance	the acceptable bias (in km or degrees. Supposed to be in, a plane approximation) between [lat,lon] and the nearest data point.

Returns:: true if the coincidence has been found

References get_index().

const bool CERESFileData::get_index	(	const float &	lat,
		const float &	lon,
		const double	time,
		int &	index,
		const float	coloc_tolerance = `CERESFileData::colocation_tolerance`
	)			`[virtual]`

search the index of the nearest point in the data to (lat , lon ) It uses a brute force search on the whole data. For better performances, override this method, and use more specifics way like sort the pixels by increasing (lat,lon) then dichotomic search on it... Only the points that have a distance to ( lat, lon ) inferior to coloc_tolerance will be considered

Parameters:

	lat	the latitude
	lon	the longitude
	time	the time of the observation. If -1., skipped
	index	the index of the eventual coincidence (or -1)
	coloc_tolerance	the frame in which 2 points are considered as colocated

Returns:: true if coincidence found

References FileData::contain_time(), free_geolocation_data(), get_ceres_lat(), get_ceres_lon(), get_nb_geo_points(), is_geolocation_data_loaded(), SatelliteFileData::lat_data, load_geolocation_data(), and SatelliteFileData::lon_data.

Referenced by contain_location(), get_index(), and get_nearest_point_distance().

const string CERESFileData::get_instrument ( ) const [inline]

read the instrument in use in this product

Returns:: the instrument

const int CERESFileData::get_nb_geo_points ( ) const

access the number of differents geographical points in the file

Returns:: the number of different points

Referenced by get_index().

const float CERESFileData::get_nearest_point_distance	(	const float &	lat,
		const float &	lon,
		const float	coloc_tolerance = `CERESFileData::colocation_tolerance`
	)

compute the distance to (lat,lon) of the nearest point in the data If coloc_tolerance is given, it will compute only the distance of the points that have a distance to ( lat, lon ) inferior to coloc_tolerance

Parameters:

	lat	the latitude
	lon	the longitude
	coloc_tolerance	the -/+ maximal tolerance for 2 points considered as colocated

Returns:: the distance to the nearest point, or -1 if no point in the colocalisation frame has been found.

References free_geolocation_data(), get_index(), is_geolocation_data_loaded(), SatelliteFileData::lat_data, load_geolocation_data(), and SatelliteFileData::lon_data.

const float CERESFileData::get_nearest_point_distance	(	const float &	lat,
		const float &	lon,
		int &	coincidence_idx,
		float	coloc_tolerance = `CERESFileData::colocation_tolerance`
	)			`[virtual]`

compute the distance to (lat,lon) of the nearest point in the data Only the points that have a distance to ( lat, lon ) inferior to coloc_tolerance will be considered In the method, calls the get_index method

Parameters:

	lat	the latitude
	lon	the longitude
	coloc_tolerance	the frame in which 2 points are considered as colocated
	coincidence_idx	the index of the eventual coincidence

Returns:: the distance to the nearest point, or -1 if no point in the colocalisation frame has been found.

References get_ceres_lat(), get_ceres_lon(), get_index(), SatelliteFileData::lat_data, and SatelliteFileData::lon_data.

virtual void CERESFileData::get_pixel_coord	(	const vector< int > &	ipix,
		float &	lat,
		float &	lon,
		double &	time
	)			`[inline, virtual]`

retrieve the coordinates of a pixel using its index

Parameters:

	ipix	[IN] index of the pixel
	lat	[OUT] latitude of the pixel
	lon	[OUT] longitude of the pixel
	time	[OUT] timestamp of the pixel

const string CERESFileData::get_platform ( ) const [inline]

read the platform used in this product

Returns:: the platform

const string CERESFileData::get_product ( ) const [inline]

read the product name (CRS,...)

Returns:: the product name

const string CERESFileData::get_radix ( ) const

return the radix of the file, actually the file name without the date and the dot. Ex : the radix of the file "CER_CRS_Terra-FM2-MODIS_Sample_000000.2001010101" is "CER_CRS_Terra-FM2-MODIS_Sample_000000"

Returns:: the radix

const string CERESFileData::get_version ( ) const [inline]

access the version of the CERES file

Returns:: the version

virtual void CERESFileData::get_vindex	(	vector< vector< int > > &	v_index,
		const float &	lat,
		const float &	lon,
		const float	colocation_tolerance = `CERESFileData::colocation_tolerance`
	)			`[inline, virtual]`

build the list of indices of pixels that are in colocation tolerance, sorted by increasing distance to (lat,lon) If (lat,lon) is not found or out of the colocalisation_frame, returns an empty vector

Parameters:

	lat	the latitude
	lon	the longitude
	colocation_tolerance	the acceptable bias (in km or degrees. Supposed to be in, a plane approximation) between [lat,lon] and the nearest data point.
