GMAOFileData Class Reference

Inheritance diagram for GMAOFileData:

Collaboration diagram for GMAOFileData:

List of all members.

Public Member Functions
	GMAOFileData (const string &name="", const int geos_version=0)
	constructor
	~GMAOFileData ()
	Destructor.
void	get_sds_fill_value (const string &sds_name, void *fill_value)
	read the fill value of the sds given in parametre This overrides the hdffiledata get_sds_fill_value method because in GMAO files, the fill value has a non standard name "missing_value"
string	get_product_id () const
	Accessor to the product ID.
int	get_geos_version () const
	Accessor to the GEOS version.
Protected Member Functions
bool	check_filename (const string &short_filename) const
void	parse_filename (const string &short_filename)
void	load_height_level ()
	if not already set, read the pressure levels in the file If the product is a 2D one, no pressure levels are defined. In this case, nothing's done.
void	load_time_level ()
	if not already set, read the time levels in the file If the product is a 2D one, no time levels are defined. In this case, nothing's done.
Protected Attributes
int	lat_lon_index_max [2]
	the bigger valid indexes for the geolocation : format {lat_index, lon_index}

---

Detailed Description

to manage the reading of GMAO meteo files

---

Constructor & Destructor Documentation

GMAOFileData::GMAOFileData	(	const string &	name = "",
		const int	geos_version = 0
	)

constructor

Parameters:

	name	the name (path included) of the file to be opened
	geos_version	the geos version of the product. If 0 (default), the class tries to automatically set it

References parse_filename().

---

Member Function Documentation

bool GMAOFileData::check_filename

(

const string &

short_filename

)

const [protected]

Check is a the file is a valid meteo data file ( the analysis is done with a filename parsing, not with parsing the data inside )

Parameters:

short_filename

string : the filename without its path

Returns:

bool : true if the filename seems to be valid, false else or in case of problem (exception...)

Referenced by parse_filename().

int GMAOFileData::get_geos_version

(

)

const [inline]

Accessor to the GEOS version.

Returns:

the GEOS major version number

string GMAOFileData::get_product_id

(

)

const [inline]

Accessor to the product ID.

Returns:

the product ID

void GMAOFileData::get_sds_fill_value	(	const string &	sds_name,
		void *	fill_value
	)

read the fill value of the sds given in parametre This overrides the hdffiledata get_sds_fill_value method because in GMAO files, the fill value has a non standard name "missing_value"

Parameters:

	sds_name	the name of the sds where to read the fill value
	fill_value	(output) the read value. Must not be NULL

References HDFFileData::get_hdf_file().

void GMAOFileData::parse_filename

(

const string &

short_filename

)

[protected]

Once the filename has been checked (that's a precondition : no verification on it are done in this method), some informations can be extracted of it :

• the date
• the hour

  Parameters:

  short_filename

  string : the filename without its path

References check_filename(), FileData::date, and Date::set_date_str().

Referenced by GMAOFileData().

---

The documentation for this class was generated from the following files:

• /home/pascal/depot/filedata/src/gmaofiledata.h
• /home/pascal/depot/filedata/src/gmaofiledata.cpp
